Τριφασικό ενεργό αρμονικό φίλτρο τύπου τεσσάρων καλωδίων

The Three-Phase Four-Wire Cabinet-Type Active Harmonic Filter (APF) offers a robust solution for harmonic mitigation in four-wire power systems. Utilising DSP+CPLD digital control and a three-level topology, this APF delivers precise harmonic compensation up to the 50th harmonic, addressing three-phase imbalances and neutral line harmonics. The modular design allows for scalable capacity through parallel connection. Housed in a robust cabinet with independent air ducts, the Three-Phase Four-Wire Cabinet-Type Active Harmonic Filter ensures reliable operation in demanding environments. Available in a range of voltage and current ratings, this APF provides comprehensive power quality improvement.

Model description:

Features:

● Use DSP+CPLD all digital control core, three-level topology technology, advanced harmonic detection algorithm and PWM control strategy to achieve accurate compensation of harmonic current.
● Adopt modular design, which facilitates parallel connection of multiple modules, takes up little space and is easy to maintain.
● The structural design of independent air ducts and independent warehouses ensures the stable operation of the equipment.
● It can filter harmonics in a wide range of harmonics, from 2 to 50 harmonics, and solve the problem of three-phase unbalance at the same time.
● The harmonic filtering rate is high. If the capacity allows, the harmonic current filtering rate can be as high as 95%. Set 100% current limiting output to ensure long-term stable operation of the equipment.

Applications:

Three-Phase Four-Wire Cabinet-Type Active Harmonic Filters find application in various sectors requiring enhanced power quality:

● Data Centres: Safeguarding sensitive equipment and maintaining operational stability by reducing harmonic currents and neutral line issues.
● Hospitals: Ensuring reliable power for critical medical equipment, minimizing disruptions caused by harmonic distortion.
● Industrial Facilities: Improving power quality for sensitive four-wire equipment and processes, increasing efficiency and reliability.
● Commercial Buildings: Reducing harmonic distortion from various loads, including computers, lighting, and HVAC systems.
● Renewable Energy Integration: Facilitating the smooth integration of renewable energy sources into the grid by addressing harmonic concerns.

Three-Phase Four-Wire Cabinet-Type Active Harmonic Filters provide a comprehensive solution for optimising power quality and equipment performance in four-wire systems.

Technical Parameters:

Model& Specification:
